TN209 HFB Plummer Block Bearing Housing (unsplit) for self aligning ball bearings with extended inner ring

In Stock

Description

This unsplit plummer block bearing housing is designed for the use with self aligning ball bearings with an extended inner ring.
The sealing rings are made from grey cast iron and fitted with a felt strips.
The outer ring of the bearing is located axially by the sealing ring. The inner ring of the bearing extends approximately 1cm over each end. This prevents contact between machine parts and the housing. The movement of the inner ring as well as axial location results from the use of a set screw which is located in a groove on one side of the inner ring. TN housings are made from GG20. A high grade grease is recommended for the lubrication of these housings.

Dimensions

Dimension	Value
Internal Diameter (ID)	45.00mm

Product Information

Property	Value
Brand	HFB
Housing Type	Plummer Block
Unit of Measure	Metric
